Industrial Wi-Fi 4 Embedded Wireless Module for UAV,UGV & Robotics Applications
The BlackPepper BKP-N2N2-2409 is an industrial embedded Wi-Fi 4 module designed for reliable wireless communication in UAV, UGV, robotics,Industrial IoT, and autonomous systems. Developed by Vizmonet, the module is built for OEMs and system integrators that require stable RF connectivity in demanding industrial environments.
Modern unmanned systems and industrial automation platforms need wireless communication that can perform reliably while operating in motion, vibration, dust, heat, and outdoor conditions. The BlackPepper BKP-N2N2-2409 helps address these challenges with a rugged hardware design, dual-radio architecture, and industrial-grade components.
The module is optimized for SWaP-C (Size, Weight, Power, and Cost), making it suitable for compact embedded systems where space and power efficiency are important. It can be integrated into industrial wireless communication systems used in defense, logistics automation, remote monitoring, smart mobility, and autonomous machines.
Industrial Wireless Connectivity for Mission-Critical Applications
Industrial wireless communication systems often operate in environments where standard consumer Wi-Fi devices may not perform reliably. Applications such as UAV communication, autonomous mobile robots, mining automation, and industrial telemetry require stable connectivity, strong RF performance, and durable hardware.
The BlackPepper BKP-N2N2-2409 is designed to support these requirements with dual independent radios operating in both 2.4 GHz and 900 MHz ISM bands. This allows OEMs to build wireless systems with improved coverage, better signal penetration, and reliable communication in industrial environments.
Key Features of BlackPepper BKP-N2N2-2409
- Dual independent radios supporting simultaneous operation in 2.4 GHz and 900 MHz bands
- IEEE 802.11 b/g/n compliant with 2×2 MIMO support
- High transmit power up to 29 dBm for long-range wireless communication
- On-board Gigabit Ethernet interface for industrial networking applications
- Integrated USB 2.0 Host interface
- Industrial-grade Qualcomm network processors QCA9550-AT4B and AR9592-AR1B
- SPI Flash – 16 MB
- NAND Flash – 256 MB
- DDR2 RAM – 256 MB
- Compact embedded design: 95 mm × 69 mm × 15 mm
- MIL-grade shock and vibration resilience
- Operating temperature range from -40°C to +85°C
Applications for the Embedded Wi-Fi Module
The BlackPepper BKP-N2N2-2409 can be used in a wide range of industrial and embedded wireless applications that require stable RF communication and rugged performance.
- UAV and drone communication systems
- UGV and unmanned ground vehicle platforms
- Autonomous mobile robots (AMR)
- Industrial IoT and Industry 4.0 systems
- Mining and heavy industrial automation
- Oil and gas wireless communication systems
- Public safety and remote monitoring platforms
Designed for OEM and Embedded System Development
OEMs developing industrial wireless products often require flexible embedded communication platforms that can support custom integration and long operational life cycles. The BlackPepper BKP-N2N2-2409 is designed to help reduce development complexity while supporting reliable wireless performance for industrial deployments.
As part of Vizmonet’s industrial wireless product portfolio, the module supports embedded system developers working on industrial automation, wireless networking, unmanned systems, and connected edge devices.
Why Industrial Wireless Modules Matter
Industrial wireless modules play an important role in modern connected systems. Unlike consumer Wi-Fi devices, industrial embedded modules are designed for continuous operation, long-term reliability, wider operating temperatures, and stable communication in harsh environments.
For industries adopting automation and autonomous technologies, reliable RF communication helps improve operational efficiency, remote monitoring, machine connectivity, and real-time data transfer.
About Vizmonet
Vizmonet is a wireless technology company specializing in RF engineering, embedded wireless systems, industrial Wi-Fi modules, and turnkey manufacturing solutions. The company develops wireless communication products for Industrial IoT, robotics, autonomous systems, and mission-critical industrial applications.
